Machine frame
|
Cast iron body, aging treatment, more thickness steel material, much more solid and stronger
|
|
Electrical control cabinet
|
Independent electrical control cabinet, much more safety, user friendly
|
|
Controller Programm
|
2GB COLORED LCM control handle cooperation, support USB Flash Disk transmitting directly, no memory capacity limit, has more function of restoring from power off, continue working on break point during working, working time anticipation etc.
|
|
|
Lead transmitting parts
|
X,Y, Z--Rolling ball screw from Germany
|
|
|
Lead transmitting guide
|
X,Y,Z--THK linear rail from Japan
|
|
|
Motion Speed
|
6000~15000mm/min
|
|
|
xyz Working stroke
|
800 mm x 700 mm x 90 mm
|
|
|
Max. thickness of material
|
100mm
|
|
|
xyz resolution
|
0,01 mm
|
|
|
Software compatibility
|
ARTCAM, Type3, Casmate, Proe, UG, Artgrave ect.
|
|
|
Software free of charges
|
Original Type3 3D Engraver version
|
|
|
Dictate format
|
HPGL, G-code
|
|
|
Warranty
|
14 months since shipping date
|
|
|
Technical characteristics
|
|
|
Power of Mainshaft
|
3000W constant power inverter driven spindle motor
|
|
|
Speed of Mainshaft
|
0~24000 RPM /min
|
|
|
Diameter of cutter
|
6 mm, 12.7 mm (optional)
|
|
|
Cooling
|
water-cooled cutter (optional)
|
|
|
application
|
Wood working, Advertising technology, model making, electrical engineering, industry, outdoor advertising, engraving technology, illuminated advertising etc.
|
|
|
Power supply
|
AC220 ±10% 50HZ, AC380 ±10% 50HZ
|
|
|
Power consumption
|
4500 W
|
|
|
Physical characteristics
|
|
|
Measures (+package)
|
1420 x 1250 x 1750 mm
|
|
|
Weight (+Package)
|
480 kg
|
|
